1000h V Fender High Compression Stable Performance Safe Fit Easy To Install

1
MOQ
US$14-US$520
цена
1000h V Fender High Compression Stable Performance Safe Fit Easy To Install
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Наименование продукта: Фендер из резины
Размер: Настраиваемый
Цвет: Черный
Особенности: Высокое поглощение энергии
Приложение: Пристань судна
МОК: 1
Логотип: на заказ
Материал: НР
Выделить:

1000h V Fender

,

Safe Fit arch rubber fender

,

Stable Performance arch rubber fender

Основная информация
Place of Origin: China
Фирменное наименование: Hongruntong Marine
Сертификация: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Model Number: HM-ARF09
Оплата и доставка Условия
Packaging Details: Pallet, Wooden Box
Delivery Time: 5-7 Work Days
Payment Terms: T/T, L/C, D/A, , D/P, Western Union, MoneyGram
Supply Ability: 1160 Pcs Per Month
Характер продукции

1000h V Fender High Compression Stable Performance Safe Fit Easy To Install



Description



Made from premium marine-grade rubber compounds, Arch Fenders are built to withstand harsh marine environments, including UV rays, saltwater, and temperature fluctuations. Their rugged construction ensures minimal wear over time, even under continuous heavy-duty use. With minimal maintenance requirements, these fenders provide reliable, long-term service and a high return on investment.





Specifications



Product Name

Arch Rubber Fender

Material

Natural rubber, Silicone rubber

Colour

Black, or customized

Surface

Smooth

Size

Height

200-1000mm

Length

1000-3500mm

All sizes can be customized

Physical Properties

Polymer Content

100% virgin

Working temperature

-50℃~240℃

Tensile strength

≥16 mpa

Density

90+/-5 Per 100mm in

Hardness

50-70 (shore A)

Elongation

≥400%

Features

1. Through high temperature resistant

2. Excellent tear resistant, oil resistant, aging resistant

3. Resistant to industrial acid & alkali and good elastic

4. Built as per PIANC2002

Application

Multi-Purpose-Terminals, RoRo ramps, Passenger Vessel Terminals, Barge



Model

W

B

F

C

H

[mm]

[mm]

[mm]

[mm]

[mm]

HM-ARF200H

400

320

145

128

200

HM-ARF250H

500

410

175

160

250

HM-ARF300H

600

490

225

196

300

HM-ARF400H

800

670

300

260

400

HM-ARF500H

1000

840

375

325

500

HM-ARF600H

1200

1010

450

390

600

HM-ARF800H

1600

1340

600

520

800

HM-ARF1000H

2000

1680

750

650

1000



1000h V Fender High Compression Stable Performance Safe Fit Easy To Install 0





Features



Excellent Shear Resistance
Built to handle lateral movement and dynamic shear forces caused by vessel drift or tidal variations without tearing or deformation.



Abrasion Resistant Surface
Outer surface is resistant to friction and wear from repeated vessel contact, especially under rough berthing conditions.



Compact and Robust Design
The simple arch profile provides outstanding performance in a compact structure, ideal for space-limited docking areas.



Wide Range of Sizes
Available in standard heights from 200mm to 1200mm (or more), allowing easy selection based on vessel type and dock height.





Applications



► Coastal piers



Inland terminals



Tugboat landings



Workboat berths





Advantages



Long Term Customer Relationships
Many of our clients have worked with us for over a decade, a testament to our consistent product performance and service reliability.



OEM ODM Capability
We support private labeling and customized designs, enabling global partners to build their own fender brands with our manufacturing support.



Corrosion Resistant Mounting Hardware Available
We supply full fender systems, including galvanized or stainless-steel bolts, plates, and accessories for marine durability.



Fast Prototyping and Sample Production
For custom projects or tender requirements, we can produce samples within short lead times for client approval.





FAQ



1. What materials are Arch Rubber Fenders made from?
They are made of high-quality natural and synthetic rubber compounds, designed for durability, UV resistance, and marine environment tolerance.



2. How long is the typical service life of these fenders?
With proper maintenance, Arch Rubber Fenders can last 10 to 20 years or more in marine applications.



3. Are Arch Rubber Fenders suitable for all types of vessels?
Yes, they are versatile and used for ferries, cargo ships, tankers, naval vessels, and tugboats.



4 How are Arch Rubber Fenders installed?
They are typically bolt-mounted onto quay walls or fender panels using standard fixing brackets and hardware.



1000h V Fender High Compression Stable Performance Safe Fit Easy To Install 11000h V Fender High Compression Stable Performance Safe Fit Easy To Install 21000h V Fender High Compression Stable Performance Safe Fit Easy To Install 31000h V Fender High Compression Stable Performance Safe Fit Easy To Install 4
